MaxiTPMS ITS600 PAKET
Originalna cena je bila: 264. 000, 00 din.198. 000, 00 dinTrenutna cena je: 198. 000, 00 din.
Opis
MaxiTPMS ITS600 + 50 kom. MX senzora. Akcija traje do isteka zaliha.
ITS600 je bežični Android tablet, koji omogućava kompletnu TPMS dijagnostiku i servisne funkcije.
Uređaj koristi Bluetooth interfejs komunikaciju sa vozilom (VCI) i ekran osteljiv na dodir, veličine 5.5“ inča.
Poseduje 4 programska moda MX senzora i kompatibilan je sa svim vozilima koji su opremljeni TPMS-om iz SAD-a, Azije i Evrope.
Funkcije ITS600 uređaja su mnogobrojne, poput aktiviranja, čitanja i ponovnog učenja svih poznatih senzora, OBD2 ponovnog učenja, programiranja MX-senzora, kopiranja pomoću OBD senzora, čitanja i brisanja TPMS sistemskih kodova, skeniranja DOT broja, obaveštavanja o isteku pneumatika i prikaz podataka uživo.
Karakteristike:
• Aktivira, čita i ponovo uči sve poznate senzore
• OBDII ponovno učenje za većinu vozila
• Programiranje MX-senzora da zamene 99% OE senzora
• Kopiranje pomoću OBD senzora za brži servis
• Četiri programska moda MX senzora; paketni program do 20 MX-senzora
• Uključuje bežični Bluetooth komunikacijski interfejs za vozilo (VCI)
• Resetovanje vrednosti pritiska u gumama
• Čitanje/brisanje TPMS sistemskih kodova i prikaz podataka uživo
• Besplatna ažuriranja Wi-Fi softvera za životni vek alata
Dodatne informacije
| Aktivacija softvera | Bez Aktivacije, Sa Aktivacijom |
|---|
SPECIFIKACIJE
| Recommended Use | Indoor |
| Operating System | Android™ 9.0 |
| Processor | Quad-core processor (1.5 GHz) |
| Memory | 1GB RAM DDR4 & 64GB ROM |
| Display | 5.5-inch LCD capacitive touchscreen with 1280×720 resolution |
| Connectivity | • Wi-Fi • USB 2.0, Type C • BT |
| Sensors | Light sensor for brightness auto adjust |
| Audio input/output | Input: N/A Output: Beep |
| Power and Battery | • 3.8 V/5000 mAh lithium-polymer battery • Charges via 5 V AC/DC power supply |
| Battery Charging Input | 5 V/2 A |
| Power Consumption | 600 mA (LCD on with default brightness, Wi-Fi on) @3.8 V |
| Operating Temp. | -10 to 45°C(14 to 113°F) |
| Storage Temp. | -20 to 60°C (-4 to 140°F) |
| Dimensions (W x H x D) | 183.0 mm (7.2”) x 89.0 mm (3.5”) x 22.0 mm (0.87”) |
| Net Weight | 368 g (0.8 lb.) |
| Protocols | ISO9141-2, ISO14230-2,ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610, GM UART,UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.66 |
Poređenje Uređaja
| Comparison | ITS600 | TS608 | TS508-WF | TS508 |
|---|---|---|---|---|
| TPMS & TIRE SERVICE | ||||
| Worldwide Vehicle Coverage 99%, Always Up-to-date |  |
|
|
|
| Easy Vehicle Identification | (AutoVIN, VINscan, QR code/Barcode scan, Plate Scan, Manually select/input) |
(AutoVIN, Manually select/input) |
(Manually select) |
(Manually select) |
| Activate, Read, Relearn All Known TPMS Sensors | |
|
|
|
| Four Programming Options | |
|
|
|
| Autel Sensor Batch Programming | (Up to 20 sensors) |
(Up to 16 sensors) |
(Up to 16 sensors) |
(Up to 16 sensors) |
| OBDII Relearn / Automatic Relearn / Stationary Relearn | |
|
|
|
| Relearn Procedure Guide | |
|
|
|
| Exclusive TPMS Status Screen | |
|
|
|
| Indicate sensor OE part number | |
|
|
|
| Check MX-Sensor Information (ID, Battery, etc.) | |
|
|
|
| Tire Pressure Placard Value Reset | |
|
|
|
| Unlock TPMS ECU for old Toyota/Lexus, Integrated into OBD relearn | |
|
|
|
| Test Remote Key Entry (RKE) | |
|
|
|
| Read/Clear Codes for TPMS System | |
|
|
|
| Special Functions (e.g. View Live Data for TPMS System) | |
|
||
| DOT Scan, Tire Expiration Notice, Tire Recall Lookup | |
(Coming soon with Autel-cloud based app) |
||
| Test Report | |
|
(View on PC) |
(View on PC) |
| TPMS Software Update | Free Update | Annual Update Fee | Free Update | Free Update |
| DIAGNOSTICS | ||||
| All System Diagnostics & All Maintenance Service | Free OLS, SAS, BMS, EPB; Optional purchase of Pro Upgrade for All System Diagnostics & All Maintenance Service |
|
||
| Diagnostic Software Update | All System Diagnostics and Services updates is FREE for 1 Year with Pro Upgrade purchase. New software updates for these features will require a new ITS600 Pro Upgrade purchase. |
Annual Update Fee | ||
| SOFEWARE | ||||
| OPERATING SYSTEM | Android 9.0 | Android 4.4 | ||
| HARDWARE | ||||
| Display | 5.5 inch TFT LCD-touch, 1280×720 | 7 inch TFT LCD-touch, 1024×600 | 2.8 inch TFT LCD, 320×240 | 2.8 inch TFT LCD, 320×240 |
| Camera | 8 MP | |||
| Flash / RAM / SD | 64GB / 1G; SD card up to 64G (Optional) | 32G / 1G; SD card up to 32G (Optional) | 16M / 3M | 16M / 3M |
| Lithium-ion Battery | 3.8V/5000mAh | 3.7V/5000mAh | 3.7V/3200mAh | 3.7V/3200mAh |
| Vibration reminder, Microphone voice remote assistance | |
|||
| ACCESSORIES | ||||
| Tread Depth & Brake Disc Wear Examiner TBE200 / TBE100 | (Sold separately) |
|||
| Thermal printer | (Sold separately) |
